Blow Down Tank
"Safe Atmospheric Discharge Vessel for High-Pressure Boiler Blowdown"
IBR 1950
Certified
Technical Specifications
Volume Capacity
500 Liters to 5,000 Liters volume rating
Construction Shell
Boiler Quality Steel IS 2002 or SA 516 Gr. 70
Design Pressure Rating
Built to safely handle discharge up to 10.0 kg/cm²
Discharge Temp Handling
Rated for incoming blowdown water up to 180°C
Design Codes
IBR statutory approval & ASME Sec VIII Div 1 guidelines
Key Performance Features
Internal anti-splash diffuser pipe breaks down incoming blowdown velocity and flash energy
Large oval manway provides full access for periodic internal inspection and cleaning
Dished top and bottom heads engineered for safe venting of flash steam to atmosphere
Mounted on triple structural support legs anchored to individual concrete plinths
