Steam Distribution Header
"Heavy-Wall Main Header manifolds to Split Plant Steam Safely"
IBR 1950
Certified
Technical Specifications
Manifold Shell Diaz
150mm up to 600mm heavy-walled pipes
Operating Temp limits
Steam saturated conditions up to 240°C
IBR Registration
Full statutory registration with custom drawings certified by local inspector
Flange Slabs
ANSI Class 150# or Class 300# slip-on steel flanges
Hydrostatic Test Rating
Sustains full 30.0 kg/cm² hydrostatic pressure
Key Performance Features
Fabricated solely from thick-walled seamless pipes (ASTM A106 Grade B)
Weld nozzles are reinforced to prevent physical stress fractures at higher velocities
Features deep bottom drain pockets to instantly extract condensates
Equipped with pressure gauge nozzles for real-time monitoring of downstream branches
